Technical Specifications

Order Code

AST-QUKBM-PWF

AC Input

100 – 240 VAC, 50/60 Hertz,
115 VAC – 0.5 A / 230 VAC – 0.3 A, 30.5 W

AC Connectors

PowerCON TRUE1 IN/OUT compatible

DC Output

12 VDC – 2 A, 24 W

DC Connectors

1 x 6pin connector

IP Rating

IP20

Ambient Operating Temperature

0 – 40 °C / 32 – 104 °F

Weight

320 g / 1.06 lbs

Dimensions (L x W x D)

118.7 mm x 74.4 mm x 48.9 mm /
4.67" x 2.93" x 1.93"

All specifications provided are typical values and may be subject to change without prior notice.
