Technical Specifications

Order Code

PWB-1-100

AC Input

100 VAC – 240 VAC, 50/60 Hertz, 0.93 A / 115 VAC, 0.48 A /230 VAC

AC Connector

PowerCON TRUE1 IN/OUT

DC Output

24 VDC – 100 W combined on two outputs

DC Connector

2 x DC Barrel (5.5 mm / 2.1 mm)

Data Input

XLR-DMX, ART-Net (1 Universe), sACN (1 Universe)

Data Output

DMX via 2 x DC sockets – DMX via 5-pin XLR

Data Sockets

5-pin XLR IN/OUT, RJ45 input

Housing Material

Aluminium

IP Rating unwired

IP65 (only with PB15-PLG)

IP Rating wired with PWB-CAB-0.2/-1.5/-5/-10/-15

IP65

Ambient Operating Temperature

0 – 40 °C / 32 – 104 °F

Weight

803 g / 1.8 lbs

Dimensions (L x W x D)

147 mm x 139 mm x 56 mm / 5.79" x 5.47" x 2.2"

Mounting Options

AirlineTrack / 1/4" – 20 UNC
