Technical Specifications

Order Code

AST-NETBX

Battery Runtime

12 h

Battery Lifetime

80 % after 400 cycles

Charging Time (nominal)

3 h 30 min

AC Input

100 – 240 VAC, 50/60 Hertz,
115 VAC – 5.2 A / 230 VAC – 2.9 A

AC Connector

PowerCON TRUE1 IN / OUT

DC Output

4 x 55 VDC – 1.67 A

Data Input/Output

Ethernet

Fixture Output

4 x EtherCON PoE++

Data Sockets

EtherCON IN/OUT

Ethernet Port Speed

100 Mbit/s

Fail-safe Ethernet Relay

Yes

IP Rating unwired

IP 65

IP Rating wired

IP 65

Ambient Operating Temperature

0 – 40 °C / 32 – 104 °F

Weight

2.4 kg / 5.29 lbs

Dimensions (L x W x D)

226 mm x 145 mm x 55.5 mm / 8.90" x 5.75" x 2.19"

Mounting Options

3/8" – 16 UNC, Ø 12.5 mm hole

All specifications provided are typical values and may be subject to change without prior notice.
